TECHNICAL SPEC.

• Shell
  Resin-infused TCT-U™ 3K carbon fiber shell
  ScorpionEXO's revolutionary Ultra TCT 3K Carbon fiber shell for aircraft-grade impact dispersal. Superior strength-to-weight ratio, digressive integrity, and durability.

  Advanced multi-layer EPS
  provides superior energy absorption and channels for increased airflow

  Aero-tuned shell sculpture
  helps reduce aerodynamic drag, improve balance, and maximize mobility

  Aero-Tuned ventilation
  features a Ram-Air intake system, 4 port exhaust spoiler system and EPS channels for an optimal flow-thru effect


• Safety
  Emergency Release


  EMT-friendly, quick-release cheek pads for emergency situations.

  Premium Pull Tab
  For easy chin strap adjustment.


  Titanium Double-D Ring
  High strength titanium D-ring system with industry leading durability.


  Helmet Safety Certification (ECE)
  DOT FMVSS No. 218 Certified / ECE Approved

  5 Year Warranty

  5 Year Warranty







  Emergency Release
  EMT-friendly, quick-release cheek pads for emergency situations.

  Helmet Safety Certification (ECE R22.06)
  ECE R22.06 Certified.

  Titanium Double-D Ring
  High strength titanium D-ring system with industry leading durability.


• Vision
  Ellip-Tec ll Ratchet
  Enables tool-less, quick-release visor changes in seconds. Integrated center locking mechanism ensures a tight seal against the gasket for secure operation and optimal protection.

  Dark Smoke Pinlock® MaxVision™ Ready 3D (included)
  ScorpionEXO face shield offers superb visisbilty is fitted with Pinlock® MaxVision™ technology for seamless Pinlock® anti-fog integration

  City Position
  Ratchet system with face shield preset "City Position" allows more fresh air at low speeds.

  Clear Pinlock face shield installed
  Optically superior Pinlock face shield offers 95% UV-A and UV-B protection. Clear vision hard coated (HD/HD) shield with anti-scratch properties. Combine with optional Pinlock insert for the ultimate in fog resistance.


• Comfort/Fit
  Removable/washable KwikWick® III interior
  Anti-microbial fabric keeps you cool and dry in warm weather, warm in cool weather. Fully removable, washable, and replaceable liner with advanced moisture-wicking and odor control. More durable, yet soft, hypo-allergenic KwikWick III Liner enhances your riding comfort.

  AirFit® inflation adjustment system
  represents a groundbreaking innovation by ScorpionEXO, transforming the helmet industry. Recognizing that riders have varying cheekbone shapes, this system allows for a customizable fit. By simply adjusting the inflation ball, riders can obtain a tighter fit that minimizes pressure points, resulting in reduced helmet vibration and lift at high speeds. Originally designed for the everyday rider, this feature has gained popularity and is now sought after by world-class MotoGP™ racers.

  3D Contour Laser-Cut Cheek Pads
  Each cheek pad is precision-cut using advanced 3D laser technology, ensuring a perfect, snug fit that contours seamlessly to your face.




  Optional Thinner & Thicker Pads: Optional Cheek Pad sizes are available for a more customized fit.

  KwikFit
  KwikFit 3D sculpted cheek pads feature pre-cut channels for easily putting eyeglasses on and off, enhancing comfort and convenience.

  Comm-Ready Speaker Pockets


  Integrated speaker pockets built into the EPS are compatible with most Bluetooth® communication systems.




  Speaker Pockets measure
  42MM Height X 48MM Width X 7.5MM Depth



• Comes with
  Breath Deflector and AeroSkirt (chin curtain) included
  For enhanced fog-free performance.

  Prime Helmet Box
  Custom designed Prime helmet box with top cover and side towers securely holds and protects the helmet from damage.

  Prime Helmet Sack



• Part Numbers
  Onyx


  Size	Gloss Black
  XS	R1C-2002
  SM	R1C-2003
  MD	R1C-2004
  LG	R1C-2005
  XL	R1C-2006
  2XL	R1C-2007
  3XL	R1C-2008
